Gloss Meter HGZ-11
HGZ-11 Gloss Meter
Production Feature:
lThis gloss meter is designed and manufactured with the reference to the international standard ISO 2813 and China national standard GB/T9754;
lTechnical parameters are in accordance with ASTM D2457, ASTM D523 and GB/T13891, GB/T7706, GB/T8807 standard;
lAll performance indexes meet the primary working machine requirements of metrological verification procedures of national standard JJG696-2002 "mirror gloss meter and gloss board";
lThe delicate and light appearance is very convenient to carry and use.
lAutomatic calibration, no need to manual adjustment, high stability, namely the boot measurement.
lAll intelligent design, single bond operation, one hand can realize all operations.
lLong life light source without replacement
lLCD digital display, showing clear.
lBuilt-in high capacity lithium battery can be recharged, full of electricity can measuring more than 12 hours continuously
lFeature-rich, measuring accuracy, good repeatability, cost effectiveness.
Technical Specification:
|
Product Name |
Gloss meter |
|
Model |
HGZ-11 |
|
Measurement Range |
0-2000Gu |
|
Application |
Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material. |
|
Instrument Dimensions |
122x34x60mm |
|
Projection Angle |
60° |
|
Measuring Spot |
（ellipse: long axis*minor axis）8mm*4mm |
|
Measuring Mode |
Automatic measurement/ manual measurement/single measurement/average measurement and cross measurement for a variety of combination measuring mode |
|
Standard Sample Setting |
Manually setting/bring out stored data for setting/manually setting tolerance |
|
Data Storage |
500 groups |
|
|
set standard sample in any stored data, user-define the tolerance range |
|
Language |
Chinese/English |
|
Output |
connect the micro printer to realize real-time output of measured data |
|
Division Value |
0.1Gu |
|
Repeatability |
0.2Gu |
|
Reproducibility |
0.4Gu |
|
Indication Error |
1.0Gu |
|
International Standard 60° |
ISO－2813、ASTM－C584、ASTM－D523、DIN－67530、ASTM－D2457、JND-A60、JND-P60 |
|
National Standard 60° |
GB 9754、GB 9966、GB 8807 |
|
Standard Accessories |
Power adapter/user manual/warranty certification/standard board/ software GlossW |
|
Optional Accessories |
micro-printer |
