Split Type Coating Thickness Gauge TG-602

Product Introduction:

Split type coating thickness gauge is based on magnetic induction principle and can automatically identify magnetic metal substrate, it can test the coating and layer thickness quickly , precisely and without damage. It can be used in both laboratory and project site. This instrument can be widely used in automobile industry, manufacturing industry, metal processing industry, chemical industry, commodity inspection and other testing fields. It is a necessary instrument for material protection.

It has backlight, large screen digital display, single point and multi-point calibration and other functions, and the product is resistant to high and low temperature, anti-fall, probe wear-resistant (more than 500,000 times), good test stability, test speed, suitable for various measurement environments. Its technical specifications are in full compliance with national and international standards.

It can measure the thickness of non-magnetic coating all magnetic substrates, for example, paint on steel and iron, powder coating, plastic, porcelain, chromium, copper, zinc and so on.

Product Features:

• Measurement methods: Fe-Magnetic Induction;
• The spring-guided probe with super wear-resistant carbide probe can ensure the probe has constant pressing force and stable sampling value when measuring on hard or rough surfaces;
• The magnetic matrix can be quickly and automatically identified;
• High precision, good stability, 1-5μm ultra-thin coating can be measured;
• Measuring speed up to 0.3 seconds/time;
• The digital display is sharper on the large screen;
• Two shutdown mode: manual shutdown mode and automatic shutdown mode;
• Wide measuring range and high resolution;
• Digital backlight display, ignore the difference, suitable for night use;
• Measurement mode: single/continuous measurement;
• It can convert μm/MIL;
• New design of shell and internal structure, enhance product beauty, anti - fall, anti - impact ability;
• Good accuracy of light touch measurement.

Technical Specifications:

Standard delivery:

Commodity	Quantity	Notes
Calibration foil （50μm、100μm、250μm、500μm、1000μm）	1 Set（5 pcs）	0-2000μm and above is equipped with 2000μm calibration standard plate
Iron matrix	1 Pic	------
Operation Manual	1 Set	------
Battery	2 Pic	------
Warranty card、Certification	1 Pic	------



Optional Accessories：

Replaceable large V - shaped workpiece fixed slot	Application: Suitable for round bar workpiece with diameter less than 100mm
